Hello!



Today's post is about the basics of EV charging.



"AC charging, DC charging — do you actually know what sets them apart?"



Electrification isn't limited to passenger EVs anymore. Industrial electrified equipment like electric excavators and electric wheel loaders is expanding fast too. The underlying charging principles are largely the same across these machines, so understanding today's topic will help no matter what kind of electrified equipment you're dealing with.



If you've ever stood at a charging station wondering "is this AC or DC?" or "does this connector even fit my car?", you're not alone. Let's clear up the fundamentals in this post.



AC vs DC: What's the Real Difference?



EV charging falls into two broad categories: AC (Level 1/2) charging and DC fast charging. It sounds like a simple speed difference, but the two methods actually deliver power to the battery in fundamentally different ways.



With AC charging, the vehicle receives alternating current, and the onboard charger (OBC) inside the car converts it to direct current before storing it in the battery. Power output typically ranges from 3.3kW to 11kW, and a full charge from empty takes roughly 6 to 10 hours.



DC fast charging works differently — the charging station itself houses a large-scale conversion unit and feeds direct current straight into the battery, bypassing the onboard charger entirely. That skips a conversion step, which means less energy loss and much faster charging. With the latest ultra-fast chargers, going from 10% to 80% can take as little as 20 minutes.



That's why AC charging is typically used overnight at home or at the office where the car sits for hours, while DC fast charging is reserved for topping up quickly during a trip. AC charging is also generally considered gentler on the battery, which is thought to be better for long-term battery health.





One question I get a lot from a development standpoint is "why are DC fast chargers so much bigger and heavier?" This is exactly why — they have to house a high-capacity AC-DC conversion unit and a cooling system inside the charger itself, which naturally makes them bulkier than AC chargers.



Charging Connector Types



Since the charging methods differ, connector standards vary too. In South Korea, DC Combo (CCS1) has become the standard, adopted by most domestic and imported EVs including Hyundai and Kia. Its big advantage is that it handles both AC and DC charging through a single port.



Standards vary by region worldwide. Europe primarily uses CCS2. Japan originally developed and rolled out its own standard, CHAdeMO, though the industry there has gradually been shifting toward the CCS family in recent years.



North America has seen a major shift recently. Tesla's proprietary NACS (North American Charging Standard) was formally standardized as SAE J3400 in 2023, and a growing number of automakers have since adopted it, pushing the region toward NACS as the emerging common standard. Like DC Combo, NACS handles both AC and DC charging through a single connector.





Because standards differ from region to region, if you're planning to rent or drive an EV abroad, it's worth checking in advance which connector standard is dominant there. Adapters exist, but not every combination is supported.



Good to Know Before You Charge



People often mix up kW and kWh. kW (kilowatt) describes how fast power is being delivered at any given moment — think of it as a rate. kWh (kilowatt-hour) describes the actual amount of energy stored in the battery. For example, charging at 7kW for one hour adds roughly 7kWh to the battery.



Pricing differs between AC and DC charging too. AC charging generally costs less per kWh, while DC fast charging carries a premium due to the equipment and infrastructure involved. If you charge frequently, relying on AC charging whenever possible tends to be the more cost-effective habit.



If you want to preserve battery longevity, it helps to remember the "10 to 80 percent" guideline. Rather than routinely draining the battery to 0% or charging all the way to 100%, keeping it within the 10-80% range is generally understood to reduce stress on the battery cells. This matters even more if you rely on DC fast charging often.



Lastly, during extreme heat or cold, charging speed may slow down noticeably because the battery management system is actively regulating temperature. This isn't a malfunction — it's a normal safety mechanism designed to protect the battery.
